TD4-1300 Amplifier

350.0 USD ($)/Unit

Get a Price/Quote

Product Details:

Frequency (MHz) 20Hz 20kHz Kilohertz ( KHZ )
Power 220-240 Volt (v)
Weight (kg) 13 Kilograms (kg)
Color Black
Dimension (L*W*H) 483 x 390 x 88 Millimeter (mm)
Warranty Yes
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

TD4-1300 Amplifier Price And Quantity

Minimum Order Quantity 1 Unit
Price 350.0 USD ($)/Unit

TD4-1300 Amplifier Product Specifications

Warranty Yes
Frequency (MHz) 20Hz 20kHz Kilohertz ( KHZ )
Dimension (L*W*H) 483 x 390 x 88 Millimeter (mm)
Color Black
Power 220-240 Volt (v)
Weight (kg) 13 Kilograms (kg)

TD4-1300 Amplifier Trade Information

Payment Terms Cash in Advance (CID)
Supply Ability 1000 Unit Per Month
Delivery Time 7 Days
Main Export Market(s) Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa, Asia

Product Description

TD series was born with an aim to drive huge scale of sound system for both of touring and installation.The series includes 2 models with power cover 4ch*3000W/4ohms and 2ch*4000W/4ohms which deliver enough outputs to drive midhigh speaker and subwoofer.it is designed with half-bridge SMPS+ real class D that make sure output clear sound quality.last but most important is its reliability& competitive price.

2,Feutures:

Four channels of individuallyClass D amplificationmodule
Overdesigned switch mode power supply
Up to 12.000 watts RMS total output (4 x 3.000 W RMS)
Multi-stage peak & RMS limiters for each channel.
Ultra lightweighted (12.5 kg only)
Full protection: Over AC voltage; troublesome signals ; DC; thermal; short circuit; muteat power on/off

3,Applications:

Sound reinforcement applications with mid power density and good
Sounding requirements.
Small to mid sized bar/cafe/lounge installation.
Portable or rental industry PA system.

Model	TD4-1300	TD2-2000
Channel Number	4	2
Rated Output Power 8ohm(THD=1%,1kHz)	4x1600w	2x2000w
Rated Output Power 4ohm(THD=1%1kHz)	4x3000w	4x4000w
Maximum RMS voltage swing (THD=1%,1kHz)	116V	125V
Slew rate (at 1 kHz)	50V/us
Input sensitivity(at rated output power or voltage, 1 kHz)	l.0Vrms,32dB,26dB
THD 0.1 Wfull power (typical value 0.02%)	< 0.05%
IMD-SMPTE 0.1 W full power (typical value 0.05%)	< 0.05%
DIM30 0.1 W full power (typical value 0.05%)	< 0.05%
Crosstalk (ref.1kHz, at 10% rated output power 8Q)	70dB
Frequency response(ref.20-20kHz, 10%power, 8ohm load)	20Hz-20Khz(0.5dB)
Input impedance	Balance 20kohm ,unbalance 10kohm
Damping Factor (ref.100Hz,8ohm output load)	400
Signal to noise ratio (a weighted 20Hz-20kHz)	>105dB
Power Requirements	AC100-240V(50-60Hz)
Protection	over heat/thermal output power control/long term output power control output short-circuit/overload protection/DC protection
Dimensions (WxDxH.mm)	483x390x88
Net weiht(KG)	13	13.5
